Two Cylinder Manual Start 2 Stroke 15hp Outboard Motors

Date:2020-06-04  Click:277   Share to:

  • Two Cylinder Manual Start 2 Stroke 15hp Outboard Motors

    Specification and pictures:

    MODELS

    BMMPP OS-002

    Max. output

    15HP/11.00KW

    Full Throltle Operating Range

    4500-5500rpm

    Stroke

    2

    Cylinder

    2

    Displacement

    246ml

    Bore*Strock

    56*50mm

    Compression Ratio

    6.8:1

    Length*Width*Height

    873*332*1040mm

    Weight

    36kg

    Gear Ratio

    2.08(27:13)

    Gear Shift Position

    F-N-R

    Ignition System

    CDI

    Cooling System

    Water-cooling

    Starting System

    Manual

    Control System

    Till control

    Lubrication System

    Mixed Fuel & oil

    Capacity Of Fuel Tank

    24l

    Recommended Oil

    Regular lead-free gasoline

    Recommended Lubricant

    2 strock outboard engine lubricant

    Recommended Gear Oil

    Hypoid gear oil-SAE#90

    Recommended Propeller

    J




    Describtion:

    BOCHI Marine Equipment Department is a total solution provider with his head office in Chongqing Bochi Machinery Import and Export Co.,ltd.we are able to provide value added services and qualified marine equipments.

    Outboard motor is one of our main products, Including diesel outboard motor, gasoline outboard motor, Electric propulsion outboard motor and some small trolling motor. Power varied from 2 hp to 90 hp, and we also can supplied other famous brand outboard motor like Yamaha, suzuki and so on.

    1.The outboard motor is fit for fiberglass boat, inflatable boat, aluminum boat and other sail boat,fishing boat.

    2.CDI ignition system makes the outboard motor start easier

    3. some parts for free with every motor

    4.Long term reliability

    5.Durable , High performance, reasonable fuel consumption , easy for service

    Cetification: CE , ISO

    Note: Please use it as the operating manual, especially if you never use a outboard motor before.

    Any questions, you can conatct us for more details.
