Single Cylinder Outboard Engine 2-Stroke 2.5HP with Short Shaft

Date:2020-06-04  Click:303   Share to:

    • Single Cylinder Outboard Engine 2-Stroke 2.5HP with Short Shaft

    Specification and picture:

    Model

    Unit

    BMMPP-OB 008S

    Overall Length

    mm(in.)

    597(23.5)

    Overall Width

    mm(in.)

    292(11.5)

    Overall Height

    mm(in.)

    968(38.1)

    Transom Height

    mm(in.)

    381(15)

    Weight

    kg

    16

    Full Throttle Operating Range

    r/min

    3800-5200

    Max.Output

    kw(hp)@r/min

    2.8(1.8)@5000

    Idling Speed(Neutral)

    r/min

    1250-1350

    Engine Type



    2 Stroke

    Cylinder



    1

    Displacement

    cc

    74.6

    Bore*Stroke(mm)



    47*43

    Ignition System

    mm(in.)

    TCL

    Control System



    Tiller Control

    Starting System



    Manual Start

    Gear Position



    Neutral-Reverse

    Gear Ratio



    2.08(27/13)

    Trim and Tilt System



    Manual Tilt

    Fuel Tank Capacity

    L

    Intrgral 1.5

    Max Fuel Consumption

    L/h

    1.4

    Engine Oil Capacity

    L

    (Fuel:Oil Ratio:50:1)

    Gear Oil Capacity

    cm3

    100

    Propeller Options

    in

    3-91/2*7" or 3-71/4*6"

    propeller choice will vary by boat size and application

    B=Back control F=Front control M=Manual start W=Electrical start S=Short Shaft L=Long Shaft


    Describtion:

    BOCHI Marine Equipment Department is a total solution provider with his head office in Chongqing Bochi Machinery Import and Export Co.,ltd.we are able to provide value added services and qualified marine equipments.

    Outboard motor is one of our main products, Including diesel outboard motor, gasoline outboard motor, Electric propulsion outboard motor and some small trolling motor. Power varied from 2 hp to 90 hp, and we also can supplied other famous brand outboard motor like Yamaha, suzuki and so on.

    1.The outboard motor is fit for fiberglass boat, inflatable boat, aluminum boat and other sail boat,fishing boat.

    2.CDI ignition system makes the outboard motor start easier

    3. some parts for free with every motor

    4.Long term reliability

    5.Durable , High performance, reasonable fuel consumption , easy for service

    Cetification: CE , ISO

    Note: Please use it as the operating manual, especially if you never use a outboard motor before.

    Any questions, you can conatct us for more details.
