﹡SG type controllable pitch propeller is servomotor in shaft,oil supply
unit in front of gearbox.
﹡Our controllable-pitch propellers are propulsion systems that can be
used with almost any type of vessel. The power spectrum ranges from
600 kW to 10,000 kW, with propeller sizes varying between approxima
-tely 1.5 to 5.0 metres.
﹡Advanced calculation methods allow the controllable-pitch propeller
systems to be optimally adapted to the vessel’s hull form, thereby
maximizing efficiency and minimizing noise generation. The simple
structure and the robust design keeps maintenance requirements to a
minimum and ensures it a long service life.
﹡Features include:
Compact, well proven, strong hub designs
Few components, robust design
Small overhang weight
Accurate stepless hydraulic pitch control
Reduced hydraulic power requirement
Easy to install, delivered as pre-assembled complete system
Under water replacement of blades
|
