Biomass Hot Air Boiler
Date:2020-06-17 Click:331 Share to:
Introduction of Biomass Hot Air Boiler
The CO2 gas released during the combustion of the boiler not only eliminates excess moisture in the greenhouse, but also helps plants to carry out photosynthesis.
v Energy conservation & Environment protection
The process from ignition to fire can be completed in one minute, and the temperature rises very quickly. The new hot air boiler structure and unique circulating oxygen supply and air distribution technology are adopted, and the fuel combustion is completed to achieve the effects of smokeless, dust-free and tasteless.
v Intelligent & Labor-saving
The microcomputer control system controls the automatic ignition, automatic feeding and automatic constant temperature of the boiler. It only needs to add 1-2 times of fuel every day. There is basically no manual participation in the whole process. The feeding method is equipped with the national patented rotary pushing technology, which solves the problem. Fuel suitability issues.
v Convenient Maintenance
The microcomputer control system displays the fault code at a glance, which is simple and convenient.
v Superior Fuel
Biomass fuel is mostly strip-shaped environmental protection new energy source processed by stem-shaped crops or sawdust. Its diameter is generally 0.8 cm, its length is 4-5 times its diameter, and its crushing is less than 1.5%-2.0%. Less than 10% to 15%, ash content less than 1.5%, sulfur content and chlorine content are less than 0.07%, nitrogen content is less than 0.5%, biomass fuel is one of the new rural construction projects supported by the government, and is supported by the state. Energy-saving and environmentally friendly fuels are renewable resources with a wide range of sources.
Product Technical Parameters
Ø 50000 calories - 200000 calories
Product model |
Unit |
RF500 |
RF1000 |
RF1500 |
RF2000 |
Rated calorific capacity |
calories |
50000 |
100000 |
150000 |
200000 |
Rated working pressure |
Mpa |
Atmospheric pressure |
|||
Thermal efficiency |
% |
89 |
90 |
91 |
91 |
Air volume |
m³/h |
680 |
1264 |
1704 |
2504 |
Air outlet (empty inside) |
mm |
150*150 |
250*250 |
300*300 |
300*300 |
Fan inlet |
mm |
Φ300 |
Φ300 |
Φ300 |
Φ300 |
Reference heating area |
㎡ |
300-500 |
700-920 |
920-1400 |
1400-1800 |
Fan cycle power |
Kw |
1.1 |
2.2 |
3 |
3 |
Draft fan power |
Kw |
0.37 |
0.55 |
0.75 |
0.75 |
Igniter power |
Kw |
4 |
4 |
4 |
4 |
Feed motor power |
Kw |
0.25 |
0.25 |
0.25 |
0.25 |
Chimney diameter |
mm |
Φ159 |
Φ159 |
Φ159 |
Φ159 |
Length |
mm |
2200 |
2500 |
2800 |
3000 |
Width |
mm |
800 |
1200 |
1250 |
1300 |
Height |
mm |
1300 |
1500 |
1700 |
2000 |
Full fuel consumption |
Kg/h |
14 |
28 |
42 |
56 |
Material storage capacity |
kg |
100 |
180 |
180 |
180 |
Total weight |
kg |
450 |
650 |
820 |
910 |
Ø 300000calories - 900000 calories
Product model |
Unit |
RF500 |
RF1000 |
RF1500 |
RF2000 |
||
Rated calorific capacity |
calories |
300000 |
400000 |
600000 |
900000 |
||
Rated working pressure |
Mpa |
Atmospheric pressure |
|||||
Thermal efficiency |
% |
92 |
92 |
92 |
92 |
||
Air volume |
m³/h |
2700 |
3166 |
3488 |
4386 |
||
Air outlet (empty inside) |
mm |
400*400 |
400*400 |
400*400 |
400*400 |
||
Fan inlet |
mm |
Φ350 |
Φ350 |
Φ350 |
Φ350 |
||
Reference heating area |
㎡ |
1800-2700 |
2700-4500 |
4500-5500 |
5500-8500 |
||
Fan cycle power |
Kw |
4 |
7.5 |
11 |
11 |
||
Draft fan power |
Kw |
2.2 |
3 |
4 |
4 |
||
Igniter power |
Kw |
4 |
4 |
4 |
4 |
||
Feed motor power |
Kw |
0.4 |
0.4 |
0.4 |
0.4 |
||
Chimney diameter |
mm |
Φ220 |
Φ220 |
Φ220 |
Φ220 |
||
Length |
mm |
3200 |
3500 |
3800 |
4500 |
||
Width |
mm |
1400 |
1500 |
1600 |
2000 |
||
Height |
mm |
22000 |
2400 |
2800 |
3500 |
||
Full fuel consumption |
Kg/h |
84 |
112 |
168 |
252 |
||
Material storage capacity |
kg |
300 |
450 |
600 |
600 |
||
Total weight |
kg |
1500 |
2100 |
3200 |
4600 |
||
