Corrugated Oil Tank Flame Arrester

Date:2020-06-17  Click:356   Share to:


    • GB Flange


    Package

    Model

    DN
    (mm)

    Dimension(mm)

    D

    D2

    L

    H

    n-d

    BMMVPPSFA001

    50

    140

    100

    220

    235

    4-14

    BMMVPPSFA002

    80

    185

    150

    280

    270

    4-18

    BMMVPPSFA003

    100

    205

    170

    325

    275

    4-18

    BMMVPPSFA004

    150

    260

    225

    425

    290

    8-18

    BMMVPPSFA005

    200

    315

    280

    495

    305

    8-18

    BMMVPPSFA006

    250

    370

    335

    595

    320

    12-18

    BMMVPPSFA007

    300

    435

    395

    655

    405

    12-23

    Body material:WCB,Stainless steel 304/316

    Fire arresting trim:Stainless steel

    The seals:PTFE,Oil resistant rubber asbestos

    Temperature:≤480℃

    Pressure:0.6~5.0 mpa

    Explosion-proof level:BS5501:IIA,IIB,IIC

    Can be used with breather valve,also can be used alone.
