BDB51－X Series Stainless Steel Explosion-Proof Mark Lights ( I I B、I I C、DIPA20)

Date:2020-06-19  Click:309   Share to:

    • BDB51－X Series Stainless Steel Explosion-Proof Mark Lights ( I I B、I I C、DIPA20)

    Scope of application:



    1. Can be used in zone 1and 2 dangerous places.

    2. Can be used in IIA、IIB、IIC，temperature classification from T1 to T16 in explosion gas environment.

    3. Can be used in zone 20、21、22；flammable dust atmosphere.



    Model implication:

    explosion proof lightexplosion proof light



    Features:



    1) Stainless stain steel shell, surface polishing, fine appearance, anti-corrosion performance is good.

    2) All kinds of transparent signs can be free to choose by the customer.

    3) When the normal power supply can be charging automatically , when the power stop can be emergency lighting, emergency lighting time of up to ninety minutes.

    4) Rechargeable batteries free maintenance, reduce the operation cost.

    5) Steel pipe or cable wiring.

    6) Conform to GB3836－2000、IEC60079、GB12476.1－2000、IEC61241  standards.



    Main technical parameters:




    Explosion proof mark

    IP rating

    Inlet thread

    Cable external diameter(mm)

    Exd II BT6

    Exd II CT6

    DIPA20TA,T6

    IP55

    G3/4

    Φ8-Φ13











    Supplied with lamps:

    Lamp type

    Rated voltage(V)

    Rated power(W)

    Emergency lighting time (min)

    Normal

    Emergency

    Normal

    Emergency

    LED

    AC 220

    DC 6

    3

    ≤90











    Inducing sign:

    explosion proof light


    Outline and installation dimensions:

    explosion proof light
