Boiler and Pressure Vessel Steel Plate

Date:2020-05-25  Click:824   Share to:

  • Boiler and Pressure Vessel Steel Plate

    Boiler and Pressure Vessel Steel Plate
    Boiler and Pressure Vessel Steel Plate

    Introduction:

    Boiler and Pressure Vessel Steel Plate mainly used for building boilers and pressure vessels such aspetroleum, chemical industry, power plant, boiler, uses in manufacturing the reactor, the heat interchanger, the separator, the spherical tank, the oil gas storage holder.

    Rolling specifications range:Thickness within 6-300mm,Width within 1500-4000mm,Length within 4500-14000mm.

    Additional technical terms: Heat treatment such as Normalized,NACE included HIC and SSCC test,UT according to A435/A435M, A577/A577M, A588/A588M and so on.

    Mainly Application:

    Widely used in petroleum, chemical industry, power plant, boiler, etc, and used to make the reactor, heat exchanger, separator, spherical tank, YouQiGuan, liquid tank, nuclear power reactors YaLiKe, boiler drum, liquefied oil steam bottle, high-pressure hose, spiral turbine hydropower station equipment and components.

    Product Description Information:

    Product

    Steel Grade/Number

    Standard

    Boiler

    and

    Pressure

    Vessel

    Steel

    Plate

    20g,16Mng,15CrMog
    12Cr1MoVg,19Mng
    22Mng,13MnNiCrMoNbg
    20R,16MnR,15MnVR
    15CrMoR,13MnNiMoNbR
    15MnNbR,15MnVNR
    16MnDR,09MnNiDR
    15MnNiDR
    12Cr2Mo1R,14Cr1MoR
    07MnCrMoVR
    07MnNiCrMoVDR
    SB410,SB450,SB480
    SPV235,SPV315,SPV355
    SPV410,SPV450,SPV490
    SGV410,SGV450,SGV480
    SBV1A,SBV1B,SBV2,SBV3
    SEV245,SEV295,SEV345
    H I,H II,10CrMo910,15Mo3
    13CrMo44,19Mn6
    BHW35
    13MnNiMo54
    1Cr0.5Mo,2.25Cr1Mo
    1.25Cr0.5Mo
    (S)A299M
    (S)A515M(Gr.60,65,70)
    (S)A204M(Gr.A,B,C)
    (S)A387M(Gr.11,12,22)
    (S)A537M(GL.1,CL.2)
    (S)A662M(Gr.A,B,C)
    (S)A302M(Gr.A,B,C,D)
    (S)A737M(Gr.B,C)
    (S)A738M(Gr.A,B,C)
    (S)A533M(I,II)
    P235GH,P265GH,P295GH
    P355GH,16Mo3,13CrMo4-5
    10CrMo9-10,11CrMo9-10
    A42,A52
    20MnHR,20HR,16MnHR
    161G430
    WDB620(low welding crack sensitive steel)



    GB713

    GB6645


    GB3531

    GB150


    JIS G3103
    JIS G3115
    JIS G3118
    JIS G3119
    JIS G3124

    DIN17155

    Thyssen
    Dillinger
    Special conditions

    ASTM,
    ASME



    EN10028-2
    NFA36-205
    Special conditions
    BS1501
    Special
     conditions

    Note:
    1. Can Z15-Z35 each brand production of layered tear resistance (thickness direction performance steel plate.)
    2. Production specifications: 8 mm-40 mm thickness and width 1500 mm to 3900 mm, length of 3000 mm to 18000 mm. Agreement by both parties, which can supply the more big specifications of the steel plate.
    3. According to the properties and delivery state user needs, steel plate can be hot rolling and controlled rolling, annealing, normalizing, tempering, is fire and tempering, conditioning and state delivery.
